SCHNEIDER- MCB 10A, 1POLE Acti9 xC60
HSN

8536

SCHNEIDER- MCB 10A, 1POLE Acti9 xC60

SKU: ZG.SCH.9101010
In Stock

Original price was: ₹430.00.Current price is: ₹138.00.

Model: A9N1P10C  MCB 6A Single Pole Acti9

Device application Distribution
Range of product Acti9
Range Acti9
product name XC60
Product or component type Miniature circuit-breaker
Device short name xC60
Poles description 1P
Number of protected poles 1
[In] rated current 10 A



In Stock
Add to Wishlist
Add to Wishlist
Categories: ,

Description

Technical Specification

Network frequency 50/60 Hz
[Ue] rated operational voltage 220…240 V AC 50/60 Hz
12…48 V DC
60 V DC
Magnetic tripping limit 8 x In +/- 20 %
Breaking capacity 10000 A Icn at 240 V AC 50/60 Hz conforming to EN/IEC 60898-1
15 kA Icu at 220…240 V AC 50/60 Hz conforming to EN/IEC 60947-2
15 kA Icu at 12…48 V DC conforming to EN/IEC 60947-2
6 kA Icu at 60 V DC conforming to EN/IEC 60947-2
[Ics] rated service breaking capacity 15 kA conforming to EN/IEC 60947-2 – 12…48 V DC
6 kA conforming to EN/IEC 60947-2 – 60 V DC
7.5 kA conforming to EN/IEC 60947-2 – 220…240 V AC 50/60 Hz
Limitation class 3 conforming to EN/IEC 60898-1
3 conforming to EN/IEC 60947-2
[Ui] rated insulation voltage 500 V AC 50/60 Hz conforming to EN/IEC 60947-2
[Uimp] rated impulse withstand voltage 6 kV conforming to EN/IEC 60947-2
Contact position indicator Yes
control type Toggle
local signalling ON/OFF indication
Mounting mode Clip-on
Mounting support 35 mm DIN rail
Comb busbar and distribution block compatibility Top: YES
9 mm pitches 2
Height 85 mm
Width 18 mm
Depth 77.5 mm
Net weight 0.115 kg
Colour White
Mechanical durability 20000 cycles
Electrical durability 20000 cycles
Connections – terminals Tunnel type terminals (bottom) 16 mm² flexible
Tunnel type terminals (bottom) 25 mm² rigid
Biconnect (top)
Wire stripping length 13 mm for top or bottom connection
Tightening torque 2 N.m
Earth-leakage protection Separate block
Product compatibility C60 auxiliary
C60 accessories

Ready to ship in 1 business day from India
