MODEL: VFD4A2MS43ANSAA DELTA- AC DRIVE 2HP/1.5Kw 3Ph. 415Vac

MODEL: VFD4A2MS43ANSAA DELTA- AC DRIVE 2HP/1.5Kw 3Ph. 415Vac

1 customer review
SKU: ZG.MS.20043015
In Stock

Original price was: ₹19,900.00.Current price is: ₹10,550.00.

SPECIFICATION:

Model Name VFD4A2MS43ANSAA
Series MS-300 Series
Input Voltage – Phase 415 V – 3 Phase
Motor Power Range 2 HP – 1.5 KW
Frequency 0 – 599 Hz
Frame Size B1
IP Level IP 20
EMC Filter Optional
Normal Duty* Amps 4.6 A
Heavy Duty** Amps : 4.2 A

APPLICATION:

1. Machine Tools
2. Textile Machines
3. Woodworking Machines
4. Packaging Machines
5. Fans
6. Pumps
7. Air Compressors
8. Rewinder Machines
9. Slitter Machines
10. Printing Machines
11. Coil Winding Machines
In Stock
Add to Wishlist
Add to Wishlist
Categories: ,
Tag:

Description

TECHNICAL SPECIFICATION:

KW 1.5KW HP 2HP Input Supply 3-Phase, 415V
Output Current 4.2Amp. Braking Chopper Built in Output Frequency (HZ) 0 to 599.00 Hz
PID Function Built in PLC Function Built-in (2k steps), MODBUS COM Built in
CANopen Optional PROFIBUS DP Optional PROFINET Optional
DeviceNet Optional Modbus TCP Optional EtherNet/IP Optional
EtherCAT Optional BACnet NA PG Close Loop Built in (With One High speed input capacity 33 khz)
KEYPAD Built in Detachable Control Mode V/F, SVC, FOC Sensorless Make Delta Series MS300

Ready to ship in 1 business day from India



Shipping Policy

Courier



Refund Policy

Bank Transfer

Additional information

Weight 1.90 kg

1 review for MODEL: VFD4A2MS43ANSAA DELTA- AC DRIVE 2HP/1.5Kw 3Ph. 415Vac

  1. admin –

    Sed perspiciatis unde omnis iste natus error sit voluptatem accusantium doloremque laudantium.

Add a review

Your email address will not be published. Required fields are marked *

DELTA- DVP12SE11T Complete network communication functions
